规格型号(specifications )
|
Model 型号 |
MONO 100W/18V |
|
Peak power Pm(W) 峰值功率 |
100(±3％) |
|
Open circuit voltage Voc(V) 开路电压 |
21.6(±3％) |
|
Max. power voltage Vmp(V)峰值电压 |
18(±3％) |
|
Max. power current Imp(A) 峰值电流 |
5.55(±3％) |
|
Short circuit current Isc(A) 短路电流 |
6.10(±3％) |
|
Dimensions(L*W*T)/ Weight(kgs)尺寸/重量 |
665*510*55mm/8.1KG |
|
solar cell / No. of cells and connections 太阳能电池片/电池片数量与连接方式 |
mono 156.75*52.25*0.19mm/36 series |
|
Module conversion efficiency组件转换效率 |
14.74%(±5％) |
|
Front cover(material/thickness) 表面封装 |
Low-iron temperd glass/3.2mm |
|
Encapsulant(material) 密封剂 |
Ethylene vinyl acetate(EVA) |
|
Frame(material/collor) 边框 |
铝制边框 |
|
Junction box protection degree 接线盒防水等级 |
≥IP65 |
|
Cable /Cable connector Model连接线/接头型号 |
MC4 |
|
STC 标准测试条件 |
Irradiance:1000W/m2,Cell temperature:25℃,AM:1.5 |
|
Max. static load ,front(e. g .,snow/wind)前风压 |
2400Pa |
|
Max. static load ,back(e. g .,wind)后风压 |
2400Pa |
|
Max. hailstone impact (diameter/velocity)最大冰雹撞击 |
25mm/ 23m/s |
|
Max. over-current (A) 最大过电流 |
15A |
|
Max. system voltage (V) 最大系统电压 |
1000V DC |
|
Application Class 应用等级 |
Class A |
|
NOCT 额定工作温度 |
48±2℃ |
|
Operating temperature limits工作温度范围 |
-40℃- +80℃ |
|
Coefficient current TK 电流温度系数 |
0.1%/℃ |
|
Coefficient voltage TK 电压温度系数 |
-0.37%/℃ |
|
Coefficient power TK 功率温度系数 |
-0.45%/℃ |
|
Life 寿命 |
≥25 years |
|
Warranty 质量 |
5 years,Pm≥80% in 10 years, Pm≥60% in 15 years (5年保证80额定功率，15年保证60%额定功率) |
|
Product Certification / Standard产品认证/标准 |
CE，ROHS（IEC61215） |
|
Other Certification其他认证 |
ISO 9001：2015 |
